The True TDR60-PTSZ1-L-S-SS-SS-1 single-zone pass-through draft beer dispenser features four solid swing doors, with two doors on each side for front and rear access. Its exterior includes a stainless steel front, sides, and countertop. The self-contained capillary tube refrigeration system uses R290 hydrocarbon refrigerant and forced-air cooling to maintain product temperatures from 33°F to 38°F. The left-mounted refrigeration assembly incorporates True’s self-cleaning RCU technology, while front air intake and discharge allow zero clearance at the sides and back. One insulated, chilled 3" diameter draft column includes a single faucet and two-way manifold, with a 15" surface-mounted drip tray trough.

The cabinet features a stainless steel floor and interior sides with an ABS plastic ceiling. High-density, foamed-in-place polyurethane insulation fills the cabinet, and white LED lighting illuminates the storage area. Field-reversible doors include a reverse-hinge kit, standard locks located in the countertop, and reinforced door thresholds. An electronic temperature control with an exterior digital display, three interior access ports, and leg levelers are included. The unit comes with a 10-foot usable power cord and NEMA 5-15P plug for connection to a dedicated 115V, 15-amp outlet.

Standard Features

• Single-zone, two-section pass-through draft beer dispenser.
• Four solid swing doors: two front and two rear.
• Stainless steel front, sides, and countertop.
• Stainless steel interior floor and sides with an ABS plastic ceiling.
• High-density, foamed-in-place polyurethane insulation with zero ozone depletion potential and zero global warming potential.
• Self-contained capillary tube refrigeration system.
• R290 hydrocarbon refrigerant.
• Forced-air cooling maintains product temperatures of 33°F–38°F.
• Left-mounted refrigeration assembly.
• True self-cleaning RCU technology.
• Front air intake and discharge.
• Zero clearance required at the sides and back.
• One insulated, chilled 3" diameter draft column with one faucet.
• Two-way manifold.
• 15" surface-mounted drip tray trough.
• White LED interior lighting.
• Standard door locks located in the countertop.
• Field-reversible doors; reverse-hinge kit included.
• Door thresholds with reinforced lips.
• Electronic temperature control with an exterior digital display.
• Three interior access ports.
• Base fitted with leg levelers.
• No shelves included.
• PDF-listed alternative keg capacities: nine homebrew barrels, eight 1/6 barrels, four slim 1/4 barrels, two 1/4 barrels, or two 1/2 barrels.
• 1/4 HP; 115V/60 Hz/1-phase; 3.2 amps.
• 10-foot usable power cord with NEMA 5-15P plug.
• Requires a dedicated 15-amp outlet.
• NSF/ANSI Standard 7 compliant for storage and/or display of packaged or bottled products.
• UL rated for outdoor use.
• Cabinet dimensions: 60" W × 27" D × 34 3/4" H.
• Height excludes the 15 3/4" draft tower and 1/4" leg levelers; depth excludes door handles.
