The True TDR52-RISZ1-L-S-SG-1 single-zone reach-in draft beer dispenser combines one solid swing door and one glass swing door with a stainless steel front, sides, and countertop. Its self-contained capillary tube refrigeration system uses R290 hydrocarbon refrigerant and forced-air cooling to maintain temperatures from 33°F to 38°F. The left-mounted refrigeration assembly features front air intake and discharge, allowing zero clearance at the sides and back. True’s self-cleaning RCU technology helps maintain condenser performance. One insulated, chilled 3" draft column includes a single faucet, a two-way manifold, and a 15" surface-mounted drip tray trough.

The cabinet has a stainless steel floor and interior sides, an ABS plastic ceiling, and foamed-in-place polyurethane insulation. The glass door features Low-E, double-pane thermal-insulated glass. Both doors include standard locks and are field reversible with the included reverse-hinge kit. Three adjustable gray PVC-coated wire shelves provide storage flexibility, while TruLumina LED lighting illuminates the interior. An electronic temperature control with an exterior digital display, three interior access ports, and standard leg levelers are included. The unit comes with a 10-foot usable power cord and NEMA 5-15P plug for connection to a dedicated 115V, 15-amp outlet.

Standard Features

• Single-zone, two-section reach-in draft beer dispenser.
• One solid swing door and one glass swing door.
• Stainless steel front, sides, and countertop.
• Stainless steel interior floor and sides with an ABS plastic ceiling.
• High-density, foamed-in-place polyurethane insulation with zero ozone depletion potential and zero global warming potential.
• Self-contained capillary tube refrigeration system using R290 hydrocarbon refrigerant.
• Forced-air cooling maintains cabinet temperatures of 33°F–38°F.
• Left-mounted refrigeration assembly.
• Front air intake and discharge allow zero clearance at the sides and back.
• True self-cleaning RCU technology.
• One insulated, chilled 3" diameter draft column with one faucet.
• Two-way manifold.
• 15" surface-mounted drip tray trough.
• Low-E, double-pane thermal-insulated glass door.
• Standard door locks located in the countertop.
• Field-reversible doors; reverse-hinge kit included.
• Reinforced lip at the door threshold.
• Three adjustable gray PVC-coated wire shelves measuring 17 11/16" W × 18" D.
• Four chrome-plated shelf clips per shelf.
• Aluminum shelf pilasters allow adjustment in 1/2" increments.
• TruLumina LED interior lighting.
• Electronic temperature control with an exterior digital display.
• Three interior access ports.
• Standard leg levelers.
• 1/5 HP; 115V/60 Hz/1-phase; 1.8 amps.
• 10-foot usable power cord with NEMA 5-15P plug; dedicated 15-amp outlet required.
• NSF/ANSI Standard 7 compliant for storage and/or display of packaged or bottled products.
• UL rated for outdoor use.
• Cabinet dimensions: 52" W × 24 7/8" D × 34 3/4" H.
• Cabinet height excludes the 15 3/4" draft tower and 1/4" leg levelers; depth excludes 1 1/2" handles.
