The True TBB24-60-2G-Z1-BST-S-1 single zone back bar cooler features glass swing doors, a stainless steel exterior, and a black sub top. Its factory-engineered, self-contained capillary tube refrigeration system uses R290 hydrocarbon refrigerant and forced-air circulation to maintain a product temperature of 35°F. True’s self-cleaning RCU technology keeps the condenser coil clean and reduces energy consumption. An electronic control manages operation, while LED interior lighting illuminates stored beverages. The cabinet is NSF/ANSI Standard 7 compliant for storage and display of packaged or bottled products.
The interior combines a stainless steel floor with heavy-gauge galvanized steel walls. High-density, foamed-in-place polyurethane cabinet insulation has zero ozone depletion potential and zero global warming potential. Low-E, double-pane thermal-insulated glass doors feature black powder-coated frames, black flat-top handles, and standard locks. Four adjustable gray PVC-coated wire shelves measure 21 11/16" W × 18" D, with four chrome-plated clips supplied per shelf. Aluminum support pilasters allow shelf adjustment in 1/2" increments. The base includes leg levelers, and the cooler is UL approved for outdoor use. Recommended installation clearance is 1" at the sides and back. The unit is factory pre-wired for a dedicated 115V/60Hz/1-phase, 15-amp outlet, with a cord and plug set included.
Standard Features
- Single zone back bar cooler with glass swing doors.
- Maintains a product temperature of 35°F.
- Factory-engineered, self-contained capillary tube refrigeration system.
- R290 hydrocarbon refrigerant.
- Forced-air refrigeration.
- True self-cleaning RCU technology for the condenser coil.
- Electronic control.
- Stainless steel exterior.
- Black sub top.
- Stainless steel interior floor.
- Heavy-gauge galvanized steel interior walls.
- High-density, foamed-in-place polyurethane cabinet insulation.
- Insulation has zero ozone depletion potential and zero global warming potential.
- Low-E, double-pane thermal-insulated glass doors.
- Black powder-coated door frames.
- Black flat-top door handles.
- Standard door locks.
- LED interior lighting.
- Four adjustable gray PVC-coated wire shelves, each measuring 21 11/16" W × 18" D.
- Four chrome-plated shelf clips per shelf.
- Aluminum shelf support pilasters with adjustment in 1/2" increments.
- Base fitted with leg levelers.
- UL approved for outdoor use.
- NSF/ANSI Standard 7 compliant for storage and/or display of packaged or bottled products.
- Factory pre-wired for a dedicated 115V/60Hz/1-phase, 15-amp outlet; cord and plug set included.
- Model:
- TBB24-60-2G-Z1-BST-S-1
- Type:
- Single Zone Back Bar Cooler
- Exterior:
- Stainless steel
- Interior:
- Stainless steel floor; heavy-gauge galvanized steel walls
- Top:
- Black sub top
- Door Type:
- Glass
- Door Style:
- Swing
- Door Glass:
- Low-E, double-pane thermal-insulated glass
- Door Frames:
- Black powder-coated
- Door Locks:
- Standard
- Number Of Shelves:
- 4
- Shelf Material:
- Gray PVC-coated wire
- Shelf Dimensions (WxD):
- 21 11/16" × 18"
- Shelf Adjustment:
- 1/2" increments
- Refrigerant:
- R290
- Temperature:
- 35°F
- Voltage:
- 115/60/1
- Certifications:
- cULus; UL EPH; UL approved for outdoor use; NSF/ANSI Standard 7 compliant for packaged or bottled products
