The True STG1RRT89-1S-1S-HC SPEC SERIES refrigerator features a one-section roll-thru design with solid front and rear swing doors. Its exterior has stainless steel doors with matching aluminum sides, while the interior features aluminum side walls and back with a stainless steel floor and ceiling. Two heavy-gauge stainless steel ramps, one per door, accommodate roll-in racks with inboard casters measuring up to 27"L × 29"D × 72"H. Racks are supplied separately by others.
The factory-engineered, self-contained expansion valve (TXV) refrigeration system uses R290 hydrocarbon refrigerant. An extra-large evaporator coil, higher-horsepower compressor, and large condenser maintain cabinet temperatures between 33°F and 38°F. Sealed, self-lubricating cast-iron evaporator fan motors and larger fan blades provide low-velocity, high-volume airflow for faster temperature recovery and shorter run times. The top-mounted system positions the evaporator outside the food zone.
High-density polyurethane insulation fills the cabinet and solid doors. Self-closing doors feature a 120° stay-open function, lifetime-guaranteed cam-lift hinges, metal handles, and bolt-style locks. Magnetic door gaskets are removable without tools, and the hinges are field reversible. Interior bumpers protect the cabinet walls from roll-in carts. Safety-shielded incandescent lighting, an exterior digital temperature display, and an epoxy-coated evaporator are included. The unit comes with a 9-foot cord and NEMA 5-15P plug.
Standard Features
- One-section roll-thru design with solid front and rear swing doors.
- Stainless steel doors with matching aluminum exterior sides.
- Aluminum interior side walls and back; stainless steel floor and ceiling.
- Two heavy-gauge stainless steel ramps, one per door.
- Accepts racks with inboard casters up to 27"L × 29"D × 72"H; racks supplied by others.
- Self-contained expansion valve (TXV) refrigeration system.
- R290 refrigerant with zero ozone depletion potential and 0.02 global warming potential.
- Cabinet temperature range of 33°F–38°F.
- Extra-large evaporator coil balanced with a higher-horsepower compressor and large condenser.
- Sealed, self-lubricating cast-iron evaporator fan motors and larger fan blades.
- Low-velocity, high-volume airflow for faster temperature recovery.
- Top-mounted refrigeration with the evaporator outside the food zone.
- High-density polyurethane cabinet and door insulation with zero ozone depletion and global warming potential.
- Positive-seal, self-closing doors with a 120° stay-open feature.
- Lifetime-guaranteed bolt-style locks and heavy-duty metal handles.
- Lifetime-guaranteed external cam-lift hinges, three per door section.
- Field-reversible hinges.
- Magnetic door gaskets removable without tools.
- Safety-shielded incandescent interior lighting.
- Exterior digital temperature display in °F or °C.
- Epoxy-coated evaporator for corrosion protection.
- Interior bumpers protect cabinet walls from roll-in carts.
- NSF/ANSI Standard 7 compliant for open food products.
- 1/3 HP; 8.9 amps; 115V/60 Hz/single-phase.
- NEMA 5-15P plug and 9-foot cord included.
- Prewired for connection to a dedicated 15-amp outlet.
