The Frymaster 2FQE60U FilterQuick® electric fryer is a dual frypot, high-production fryer system engineered for commercial kitchens that require maximum output, advanced oil management, and lower operating costs within a compact footprint. Featuring two 63 lb open frypots with large 18" × 14" cooking areas, the system delivers the production capacity of three standard 50 lb fryers while reducing oil usage, energy consumption, and required hood space. Its fully automatic FilterQuick® filtration system simplifies oil handling through front-access push-button filtration and rear oil flush functionality, helping extend oil life and maintain consistent food quality.
Equipped with the FQ4000 easyTouch® touchscreen controller, the fryer provides intuitive recipe management, programmable cooking functions, and optional KitchenConnect® cloud integration for streamlined kitchen operations. Proprietary self-standing, low-watt density heating elements transfer up to 89% of generated heat directly into the oil, improving energy efficiency while maintaining fast recovery and high throughput. Combined with a deep cold zone, precision RTD temperature probe, and durable stainless steel construction, the 2FQE60U is designed to maximize productivity, minimize operational downtime, and support demanding foodservice environments.
Key Features
- Dual 63 lb open frypot configuration for high-volume production
- FilterQuick® fully automatic filtration system with rear oil flush
- FQ4000 easyTouch® touchscreen controller with programmable recipes and menu management
- Proprietary self-standing, swing-up, low-watt density heating elements
- Up to 89% heat transfer efficiency for improved energy savings
- Large 18" × 14" frying area per frypot supporting three twin baskets simultaneously
- Deep cold zone helps extend oil life and improve food consistency
- Optional Oil Quality Sensor (OQS) for real-time oil monitoring
- Optional Automatic Top Off (ATO) system for maintaining ideal oil levels
- Optional KitchenConnect® cloud-based communication capability
- Drain safety switch and advanced filtration safety features
- Closed cabinet automatic filtration encourages more frequent filtering
- Stainless steel frypot, cabinet sides, and doors for durability and easy cleaning
- ENERGY STAR® qualified and part of the Welbilt EnerLogic® program.
| Section | Specification | Details |
|---|---|---|
| Capacity & Cooking Area | Oil Capacity | 63 lbs (31 liters) per frypot |
| Frying Area | 18" × 14" × 3.75" (45.7 × 35.6 × 9.5 cm) per frypot | |
| Frypot Configuration | Dual Open Pot | |
| Basket Capacity | (3) Twin baskets per frypot | |
| Performance & Electrical | Power Output | 17 kW per frypot |
| Heat Transfer Efficiency | Up to 89% | |
| Voltage Options | 208V / 240V / 480V | |
| 208V / 3-Phase Amperage | 48 A | |
| 240V / 3-Phase Amperage | 41 A | |
| 480V / 3-Phase Amperage | 21 A | |
| Controls Power | 120V / 1A | |
| Filter System Power | 120V / 8A | |
| Construction & System Design | Heating Elements | Proprietary self-standing flat-bar low-watt density elements |
| Temperature Control | Center-mounted RTD 1° compensating probe | |
| Filtration System | Fully automatic FilterQuick® filtration with rear oil flush | |
| Filter Pump | 8 GPM | |
| Material Construction | Stainless steel frypot, doors, and cabinet sides | |
| Oil Management Options | Automatic Top Off (ATO), Oil Quality Sensor (OQS), Bulk Oil Disposal & Fresh Fill | |
| Dimensions & Shipping | Width | 40.2" (102.1 cm) |
| Depth | 31.1" (78.9 cm) | |
| Height | 45.4" (115.2 cm) | |
| Drain Height | 11.5" (29.2 cm) | |
| Shipping Weight | 585 lbs (265 kg) | |
| Crated Dimensions | 53" W × 44" D × 53" H | |
| Shipping Class | 77.5 |
Commercial Insights
The Frymaster 2FQE60U is designed for high-volume foodservice operations seeking maximum production capacity with lower oil consumption, reduced energy usage, and improved workflow efficiency. Its dual-frypot configuration delivers the output of three conventional 50 lb fryers while using less hood space, up to 20% less oil, and significantly less energy, making it highly efficient for busy commercial kitchens. The fully automatic FilterQuick® filtration system, optional Oil Quality Sensor, and FQ4000 easyTouch® controller help reduce labor, extend oil life, and maintain consistent food quality, making the 2FQE60U particularly well suited for QSR chains, institutional kitchens, commissaries, and operations focused on automation, operational savings, and high-throughput frying performance.

- Model:
- 2FQE60U
- Controller:
- FQ4000 easyTouch
- Dimensions:
- 40.2"W x 31.10"H x 45.40"D
- Power Type:
- Electric
- Oil Capacity:
- 63 lb Per Frypot
- Fry Area:
- 18" × 14" × 3.75"
- Plug Type:
- Nema 15-60P
- Pot Type:
- Open Pot
- Power:
- 17kW Per Frypot
- Drain Height:
- 14.63"
- Voltage:
- 208/240/480
- Phase:
- 3
- Amps:
- 48/41/21
- Controls per Frypot:
- 1A/1A/120V 1A
- Filters per Frypot:
- 5A/4A/120V 8A
- Basket Lifts per Frypot:
- 2A/2A/120V 3A
- Warranty:
- Frypot=1st year: Parts + Labor, 2nd - 10th year: Parts Only
