The Atosa AWF Series Worktop Freezers with Backsplash include the AWF27SD, AWF36SD, AWF48SD, and AWF60SD models. Each unit features a stainless steel exterior and interior with a reinforced stainless steel top and foamed-in-place backsplash.
The AWF27SD has a single-door configuration, while the AWF36SD, AWF48SD, and AWF60SD feature two doors. The doors are field reversible, allowing the opening direction to be changed to accommodate the installation layout.
Each freezer is equipped with an electronic temperature controller. The self-closing doors include a stay-open feature for loading and unloading, while magnetic door gaskets help provide a positive seal when the doors are closed.
One pre-installed epoxy shelf is provided per cabinet section for organizing stored products. Pre-installed casters support unit mobility and positioning.
Standard Features
• Stainless steel exterior and interior
• Reinforced stainless steel top
• Foamed-in-place backsplash
• Electronic temperature controller
• Field-reversible doors
• Self-closing doors
• Stay-open door feature for loading and unloading
• Magnetic door gaskets for a positive door seal
• One pre-installed epoxy shelf per cabinet section
• Pre-installed casters
View this post on Instagram
- Models:
- AWF48SD
- Number Of Doors:
- 2
- Door Type:
- Solid
- Compressor Location:
- Rear Mount
- Cubic Feet:
- 12.22
- Number Of Shelves:
- 4
- Casters (inch):
- 5
- Amps:
- 4.8
- Voltage:
- 115/60/1
- HP:
- 1/4+
- Dimensions:
- 48(1/4)×30×38(7/8)
For complete product specifications and to download the file, please click below.
AWF48SD Specification Sheet
User Manual
AUR-AUF Castors Spec Sheet
